COESFELD – Cathodic Disbonding Tester (Model: 79-091)

42-200-200 Mobile impact tester for pipes – FW R 1000

Standards

ASTM G14, DIN 30 670, DIN 53 373, DIN EN 12068

Application

Mobile impact tester for testing the impact strength of pipe coatings

Features

The manually operated impact tester is a stainless steel construction consisting of a slotted pipe with a scale. The falling height can be adjusted infinitely up to 1000 mm with an accuracy of 1 mm. Thus, the impact energy can be adjusted gradually. A standard falling bolt (0 25 mm) and a standard set of weights falling masses belong to the scope of delivery. Falling bolts with different diameters and weights according to the required standards are available.

Technical Data

Falling height                           up to 1000 mm

Scale reading precision            1 mm

Falling bolt diameter                25 mm (standard falling bolt)

Max. falling weight                   5000 g

Falling masses                         408 g, 815 g, 1529 g, 3058 g (standard set of weights)

Impact energy                          4 J, 8 J, 15 J, 30 J (at a falling height of 1000mm)
