LeCroy LC334 Oscilloscope, Digital: 500MHz,2GSa/s,4ch

Form Factor     Benchtop
Bandwidth     1 GHz
Number of Channels     4 ch
Simultaneous Channels     4 ch
Simultaneous Maximum Sampling Rate/ch     1 GSa/s
One ch. only max. sampling rate     2 GSa/s
Form Factor     Benchtop
Bandwidth     500 MHz
Number of Channels     4 ch
Simultaneous Channels     4 ch
Simultaneous Maximum Sampling Rate/ch     1 GSa/s
One ch. only max. sampling rate     2 GSa/s
Max. Record Length     500000 pt/sec
Min. Vertical Sensitivity     2 mV/div
Maximum Vertical Sensitivity     5 V/div
Rise time     700 ps
Number of Bits     8 bits
Input Impedance     1 MOhm
Input Impedance (alternate)     50 Ohm
Input Coupling     AC,DC
Maximum Input Voltage     250 Vrms
Maximum Input#2 (for Impedance #2)     5 Vrms
Main time base – lowest     1 ns/div
Main time base – highest     1000 s/div
Timebase accuracy     .001 %
Trigger Source     External,Internal
Trigger Modes     Auto,Edge,Normal,Pattern,Single,State,Stop
Minimum Trigger Holdoff     10 ns
Trigger Sensitivity     5 mV
Minimum Glitch Trigger     1 ns
Display Type     Color CRT
Display Size     22.86 cm
Display modes     Auto,Normal,Single,Stop
